Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
FD3025V
FD3025V is a 3-pole molded case circuit breaker from Westinghouse designed for industrial and commercial power distribution applications. This breaker provides reliable overcurrent protection in low voltage electrical systems with a maximum continuous load current rating of 25 amperes AC per pole at all locations. Key Specifications
- Part Number: FD3025V
- Manufacturer: Westinghouse
- Amperage Rating: 25 Amps
- Number of Poles: 3
- Voltage Rating: 600VAC
- DC Voltage Rating: 250VDC
- Circuit Breaker Type: Molded Case
- Thermal Magnetic Trip Unit
Specifications
- Part Number: FD3025V
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 600
- Amperage : 25
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786679396667
- GTIN : 00786679396667
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
