FD3025L - Cutler Hammer 3 Pole 25A 600VAC Molded Case Circuit Breaker F-Frame Series C

FD3025L

FD3025L is a 3 pole, 25A, 600VAC molded case circuit breaker from Cutler Hammer, designed for reliable thermal magnetic protection in industrial and commercial power distribution systems. This Series C, F-Frame breaker features feed-thru connections, LI (Long-Time and Instantaneous) trip functions, and is rated for 35kA interrupting capacity at 480V. Suitable for use in standard load centers and panelboards, it provides dependable circuit protection for three-phase applications. This molded case circuit breaker is built for durability and safety, with line and load side lug terminals and a non-interchangeable trip unit. It is ideal for applications requiring robust protection and easy installation in F-Frame enclosures.

• Part Number: FD3025L
• Manufacturer: Cutler Hammer
• Series: Series C
• Frame Type: F-Frame
• Poles: 3
• Amperage: 25A
• Voltage: 600VAC
• Interrupt Rating: 35kA @ 480V
• Mounting Type: Feed-Thru
• Trip Unit: LI (Long-Time and Instantaneous)
• Protection Type: Thermal Magnetic
• Standards: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3025L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679451700
• GTIN : 00786679451700
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
