FD2015 - Eaton Series C Type FD Molded Case Circuit Breaker 2 Pole 15A 600VAC 35kAIC at 480VAC

FD2015

FD2015 is a Series C Type FD molded case circuit breaker from Eaton, designed for reliable protection in industrial and commercial applications. This 2-pole, 15A breaker features a 600VAC/250VDC rating, 35kAIC interrupting capacity at 480VAC, and is built with an F-frame for durability and compatibility. The breaker uses a fixed thermal/fixed magnetic trip unit for long-time and instantaneous protection, and includes line and load side terminals for easy installation. It is suitable for use in standard pressure load applications and is feed-thru connected.

• Part Number: FD2015
• Manufacturer: Eaton
• Series: Series C
• Frame: F-frame
• Poles: 2
• Amperage: 15A
• Voltage Rating: 600VAC, 250VDC
• Interrupt Rating: 35kAIC at 480VAC, 65kAIC at 240VAC
• Mounting Type: Bolt-On
• Connection: Feed-Thru, Line & Load Side Terminals
• Protection Type: Thermal Magnetic (LI - Long-Time and Instantaneous)
• Standards: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD2015
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 225A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : AB

Product Data

• UPC : 786679312209
• GTIN : 00786679312209
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3.15
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
