Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
FD1080
FD1080 is a Westinghouse 80A 1-pole molded case circuit breaker designed for reliable protection in commercial and industrial applications. This breaker features thermal magnetic trip technology and is part of the FD series, suitable for 277V AC systems. Engineered for durability and safety, the FD1080 offers a compact design with load side mounting and is rated for 35kA interrupting capacity at 277V. It is compatible with standard panel configurations and provides dependable circuit protection for lighting and power circuits.
- Part Number: FD1080
- Manufacturer: Westinghouse
- Type: FD Molded Case
- Amperage: 80A
- Poles: 1
- Voltage: 277V AC
- Interrupt Rating: 35kA @ 277V
- Mounting Type: Load Side
- Series/Frame: FD Series
- Trip Unit: Thermal Magnetic
- Frequency: 50/60 Hz
- Standards: UL Listed
Specifications
- Part Number: FD1080
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 80
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679315583
- GTIN : 00786679315583
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
