FD1070L - Eaton 70A 1-Pole Molded Case Circuit Breaker 347VAC Frame F Bolt-On Mount

FD1070L

FD1070L is a 70 amp, single-pole molded case circuit breaker from Eaton designed for reliable circuit protection.This Eaton FD series breaker features a 347 VAC maximum voltage rating with a Frame F design and bolt-on mounting. It has a 35 kA interrupt rating at 277 VAC and 18 kA at 347 VAC, suitable for industrial and commercial applications. The breaker uses line and load lug terminals and complies with industry certifications for safety and performance.

• Amperage: 70A
• Voltage Rating: 347 VAC, 125 VDC
• Poles: Single-pole
• Interrupt Rating: 35 kA at 277 VAC, 18 kA at 347 VAC
• Frame: F
• Mounting Type: Bolt-On
• Terminal Type: Line and Load Lugs
• Series: FD
• Trip Unit: Thermal Magnetic
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1070L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 70
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679043509
• GTIN : 00786679043509
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
