FD1070 - Cutler Hammer 70 Amp 1 Pole 347 VAC F-Frame Series C Molded Case Circuit Breaker

FD1070

FD1070 is a Cutler Hammer molded case circuit breaker designed for reliable protection in electrical systems.This 70 Amp, single-pole breaker features an F-frame design and is rated for 347 VAC and 125 VDC operation. It uses a thermal magnetic trip unit for dependable circuit interruption and is part of the Series C product line. The breaker is suitable for load-side terminal mounting and meets industry certifications for safety and performance.

Key Specifications
• Amperage: 70 Amp
• Poles: 1 (Single Pole)
• Voltage Rating: 347 VAC, 125 VDC
• Frame Size: F-Frame
• Series: C Series
• Trip Unit: Thermal Magnetic
• Mounting Type: Load Side Terminals
• Interrupt Rating: Standard for Series C
• Certifications: Industry Standard Compliant
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FD1070
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 70
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679312179
• GTIN : 00786679312179
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
