FD1060L - Cutler Hammer Eaton Westinghouse 60A 277V 1 Pole Molded Case Circuit Breaker Bolt-On Mount

FD1060L

FD1060L is a 60 amp, 277 volt, 1 pole molded case circuit breaker from Cutler Hammer, Eaton, and Westinghouse designed for reliable electrical protection.This FD series breaker features a fixed thermal and fixed magnetic trip unit, with a bolt-on mounting type and an interrupt rating of 35kA at 277V. It is part of the Eaton Series C F-frame, suitable for single-phase applications and rated for 125 VDC and 347 VAC as well. The breaker is UL listed and designed for panel mounting.

• Amperage: 60 A
• Voltage: 277 VAC, 125 VDC, 347 VAC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 35kA at 277V
• Series/Frame: Eaton Series C F-frame
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Phase: Single
• Certifications: UL Listed
• Connection: Feed-Thru

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1060L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 60
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782114210468
• GTIN : 00782114210468
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 2 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.6
• Certification : UL Listed
