FD1050L - Cutler Hammer 50A 277V 1 Pole Molded Case Circuit Breaker F Frame

FD1050L

FD1050L is a Cutler Hammer molded case circuit breaker rated for 50 amps, 277 volts, and single-pole configuration. It features a thermal magnetic trip unit and is part of the Series C F-frame family.This FD1050L breaker provides reliable circuit protection with a 35kA interrupt rating at 277 VAC. It is designed for feed-thru connection and fixed thermal/fixed magnetic trip functions. The breaker supports 50/60 Hz operation and is suitable for use in commercial and industrial electrical systems.

Key Specifications
• Amperage: 50 A
• Voltage: 277 VAC
• Poles: 1
• Frame Type: F Frame
• Series: Series C
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 35kA at 277 VAC
• Connection Type: Feed-Thru
• Frequency: 50/60 Hz
• Phase: Single
• Dimensions: 6" x 1.38" x 3.38"
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1050L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 50
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782114210451
• GTIN : 00782114210451
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 4
• Certification : UL Listed
