FD1050 - Eaton 50 Amp 1 Pole 347 VAC Molded Case Circuit Breaker C Series Frame F

FD1050

FD1050 is a 50 Amp, 1 Pole molded case circuit breaker from Eaton's C Series with a 347 VAC voltage rating and F frame.FD1050 features fixed thermal and fixed magnetic trip units, an interrupt rating of 18 kAIC at 347 VAC and 35 kAIC at 277 VAC, and is designed for panel mounting. It supports 50/60 Hz frequency and is suitable for single-phase applications.

Key Specifications
• Amperage: 50 Amp
• Poles: 1
• Voltage Rating: 347 VAC / 125 VDC
• Interrupt Rating: 18 kAIC at 347 VAC, 35 kAIC at 277 VAC
• Frame Type: F
• Series: C Series
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Panel Mount
• Frequency: 50/60 Hz
• Phase: Single

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1050
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 50
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679312155
• GTIN : 00786679312155
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 4
• Certification : UL Listed
