FD1045L - Eaton Series C F-Frame Molded Case Circuit Breaker 45A 347VAC 1P Fixed Thermal Magnetic Trip

FD1045L

FD1045L is a Series C F-Frame molded case circuit breaker designed for reliable protection in commercial and industrial applications. This single-pole breaker features a fixed thermal and fixed magnetic trip unit for consistent performance. Engineered for durability and safety, the FD1045L supports a maximum voltage of 347 VAC and 125 VDC, with an interrupt rating of 18 kAIC at 347 VAC and 35 kAIC at 277 VAC. It is UL Listed and built to meet rigorous industry standards for circuit protection.

• Part Number: FD1045L
• Manufacturer: Eaton
• Series/Frame: Series C, F-Frame
• Amperage: 45A
• Voltage: 347 VAC, 125 VDC
• Poles: 1 (Single Pole)
• Interrupt Rating: 18 kAIC at 347 VAC, 35 kAIC at 277 VAC
• Mounting Type: Feed-Thru
• Connection: Feed-Thru
• Trip Unit: Fixed Thermal/Fixed Magnetic
• Certifications: UL Listed
• Application: Commercial, Industrial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1045L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 45
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679093290
• GTIN : 00786679093290
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
