FD1030L - Cutler Hammer, Eaton, Westinghouse 30 Amp 1 Pole 347VAC/125VDC Molded Case Circuit Breaker, Type FD, Fixed Thermal/Magnetic, Panel Mount

FD1030L

FD1030L is a 1 pole, 30 amp molded case circuit breaker from Cutler Hammer, Eaton, and Westinghouse, designed for reliable circuit protection in commercial and industrial applications.

This circuit breaker features a fixed thermal/magnetic trip unit, panel mounting, and is part of the C Series Type FD family. It is rated for 347VAC and 125VDC, with an interrupting capacity of 18 kAIC at 347VAC and 35 kAIC at 277VAC. The FD1030L is engineered for durability and consistent performance in demanding environments.

Key Specifications
• Part Number: FD1030L
• Manufacturer: Cutler Hammer, Eaton, Westinghouse
• Amperage: 30A
• Voltage: 347VAC, 125VDC
• Poles: 1
• Mounting Type: Panel
• Interrupt Rating: 18 kAIC at 347VAC, 35 kAIC at 277VAC
• Series/Frame: C Series, Type FD
• Trip Unit: Fixed Thermal/Fixed Magnetic
• Certifications: Not specified in available data
• Connection: Feed-Thru
• Phase: 1

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1030L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685981000
• GTIN : 00786685981000
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.4
• Certification : UL Listed
