Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD1015LBP10
FD1015LBP10 is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and protection in industrial and commercial applications. This F-frame, FD-type breaker features fixed thermal and fixed magnetic trip mechanisms, delivering consistent performance across 50/60 Hz systems with both AC and DC voltage ratings for versatile installation flexibility.Key Specifications
- Amperage Rating: 15 Amp
- Voltage Rating: 347 VAC / 125 VDC
- Number of Poles: Single Pole
- Frame Type: F-Frame
- Circuit Breaker Type: FD Complete Breaker
- Trip Type: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 35 kAIC at 277 VAC, 18 kAIC at 347 VAC
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
- Terminal Configuration: Load Side
Specifications
- Part Number: FD1015LBP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 15
- Phase : 1
- Poles : 1
- AIC rating : 35kA@
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 782116128952
- GTIN : 00782116128952
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 1.55
- Certification : UL Listed
