Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCP34090TF
FCP34090TF is a 3 pole, 90 amp, 480 volt molded case circuit breaker designed for industrial and commercial power distribution applications. This Square D breaker features a feed-thru design with top feed terminals and is rated for high interrupting capacity, making it suitable for demanding environments. The FCP34090TF is part of the FCP series and utilizes a thermal magnetic trip unit for reliable protection against overloads and short circuits. It is built for bolt-on mounting and is engineered for use in 3-phase systems with a 65kA interrupting rating at 480V.
- Part Number: FCP34090TF
- Manufacturer: Square D
- Amperage: 90A
- Voltage: 480V AC
- Poles: 3
- Interrupt Rating: 65kAIC @ 480V
- Mounting Type: Bolt-On
- Series/Frame: FCP
- Terminal Type: Feed-Thru, Top Feed
- Application: 3 Phase
- Trip Unit: Thermal Magnetic
- UPC: 722511267023
Specifications
- Part Number: FCP34090TF
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCP Series
- Type : FCP
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 7
