Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCP34090
FCP34090 is a 3 pole, 90 amp, 480 volt molded case circuit breaker from Square D designed for reliable thermal magnetic protection.This Square D FCP34090 circuit breaker features a 65kA interrupting rating at 480V, FCL frame type, and feed-thru connection. It includes long time and instantaneous trip functions with line and load side lug terminals, suitable for 3 phase applications. The breaker is UL, CSA, NOM, and IEC certified.
- Manufacturer: Square D
- Series: FCP
- Amperage: 90A
- Voltage: 480V AC
- Poles: 3
- Interrupting Rating: 65kAIC @ 480V
- Frame Type: FCL
- Connection Type: Feed-Thru
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous
- Terminal Connection: Line and Load Side Lug
- Certifications: UL, CSA, NOM, IEC
Specifications
- Part Number: FCP34090
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCP Series
- Type : FCP
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 051712626347
- GTIN : 00051712626347
- Weight : 7
