Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCP340301021
FCP340301021 is a 3 pole, 480 volt, 30 amp rated molded case circuit breaker designed for bolt-on installation in power distribution equipment.
This Square D circuit breaker features an F frame design with long-time thermal and instantaneous magnetic trip protection. The unit is rated for use in Class 650/651 I-Line panelboards and switchboards, providing reliable overcurrent protection for industrial and commercial applications. The bolt-on connection method allows for quick and secure installation in compatible enclosures.
- Amperage Rating: 30 A
- Voltage Rating: 480 V
- Number of Poles: 3
- Interrupt Rating: 65 kA at 480V
- Mounting Type: Bolt-On
- Frame Type: F Frame
- Trip Functions: Long-Time (LI)
- Magnetic Hold Current: 275 A
- Certifications: UL, CSA
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
complete with 120/240V shunt trip
Specifications
- Part Number: FCP340301021
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCP Series
- Type : FCP
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 7
