Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCL24070
FCL24070 is a 2 pole, 480 Volt, 70 ampere rated molded case circuit breaker designed for panel mount applications. This thermal-magnetic circuit breaker features an F-frame design with a 100 ampere frame rating and delivers reliable overcurrent protection for industrial and commercial power distribution systems. The FCL24070 is UL listed and CSA certified, meeting the requirements of UL Standard 489 for circuit breakers. Key Specifications
- Part Number: FCL24070
- Manufacturer: Square D
- Amperage Rating: 70A
- Poles: 2
- Voltage Rating: 480VAC
- Frame Size: 100A F-Frame
- Interrupt Rating: 65kA at 480VAC
- Trip Type: Thermal-Magnetic
- Mounting: Panel Mount
- Certifications: UL Listed, CSA Certified
- Standards: UL 489
Specifications
- Part Number: FCL24070
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCL Series
- Type : FCL
- Voltage : 480
- Amperage : 70
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 3
