Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-C63/3-NA
FAZ-C63/3-NA is an Eaton 63 amp, 3-pole miniature circuit breaker designed for industrial and commercial applications.This Eaton FAZ branch protector features a C curve thermal magnetic trip unit suitable for medium inrush current applications. It supports 240 VAC and 96 VDC voltage ratings with a 10 kA interrupting rating at 240 VAC. The device mounts on a 35mm DIN rail and is UL 489 listed for safety and reliability. It includes screw terminals and is HACR rated with reverse feed capability.
- Amperage: 63 A
- Voltage Rating: 240 VAC / 96 VDC
- Poles: 3
- Trip Curve: C curve (thermal magnetic)
- Interrupt Rating: 10 kA @ 240 VAC
- Mounting: 35mm DIN rail
- UL 489 Listed
- HACR Rated
- Reverse Feed Capable
- Terminal Type: Screw
- Application: Medium inrush current
- Weight: 0.75 lb
Specifications
- Part Number: FAZ-C63/3-NA
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Section : Branch protector
Product Data
- GTIN : 04015081930623
- Dimensions : 2.1 in x 3 in x 4.1 in (Length/Depth x Height x Width)
- Weight : 0.75
