FAZ-C6/2-NA-DC - Eaton 6A 2-Pole 125VDC C Curve DIN Rail Miniature Circuit Breaker

FAZ-C6/2-NA-DC

FAZ-C6/2-NA-DC is a 6-ampere, 2-pole, 125VDC miniature circuit breaker with C curve thermal-magnetic protection, designed for medium inrush current applications including small transformers and pilot devices.FAZ-C6/2-NA-DC is a 6-ampere, 2-pole, 125VDC miniature circuit breaker with C curve thermal-magnetic protection, designed for medium inrush current applications including small transformers and pilot devices. This UL 489 certified industrial supplementary protector features a 10 kAIC interrupt rating, 50-60 Hz operation, and screw terminal connections. The breaker mounts on 35mm DIN rail and is rated for 5-10X trip setting with current-limiting capability to protect circuits from overload and short-circuit faults.

• Amperage Rating: 6 A
• Number of Poles: 2-pole
• Voltage Rating: 125 VDC
• Trip Characteristic: C curve
• Interrupt Rating: 10 kAIC
• Frequency: 50-60 Hz
• Mounting: 35mm DIN rail
• Terminal Type: Screw
• Certifications: UL 489, CSA C22.2 No. 235
• Trip Setting: 5-10X rated current
• Degree of Protection: IP20
• Operating Temperature: -25 to 75 degrees Celsius

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C6/2-NA-DC
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 125
• Amperage : 6
• Phase : 1
• Poles : 2
• AIC rating : 10kA@125V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 015081184686
• Country of Origin : Spain
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : CSA Std. C22.2 No. 235, UL 489
