Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-C5/2-NA-DC
FAZ-C5/2-NA-DC is an Eaton industrial miniature circuit breaker designed as a supplementary branch protector with a 5 amp rating and two poles.This UL 489 and CSA certified device features a C curve trip characteristic suitable for medium inrush current applications such as small transformers and pilot devices. It has a 125 Vdc voltage rating per pole, a 10 kA interrupting rating, screw terminal connections, and is designed for DIN rail mounting. The breaker is current limiting and provides reliable protection with a thermal magnetic trip unit.
- Amperage: 5 A
- Voltage Rating: 125 Vdc per pole
- Number of Poles: Two-pole
- Trip Curve: C curve (5-10X In)
- Interrupt Rating: 10 kAIC
- Mounting Type: DIN rail
- Terminal Type: Screw terminals
- Certifications: UL 489, CSA Std. C22.2 No. 235
- Application: Medium inrush current protection
- Weight: 0.5 lb
- Dimensions: 1.4 in depth x 1.25 in height x 2.97 in width
- Warranty: 1 year
Specifications
- Part Number: FAZ-C5/2-NA-DC
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ-NA
- Voltage : 125
- Amperage : 5
- Phase : 1
- Poles : 2
- AIC rating : 10kA@125V
- Connection : Din Rail
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 4015081340422
- GTIN : 04015081340422
- Country of Origin : Spain
- Dimensions : 1.4 in x 1.25 in x 2.97 in (Length/Depth x Height x Width)
- Weight : 0.5
- Certification : CSA Std. C22.2 No. 235, UL 489
