FAZ-C20/1-SP - Eaton 20A 1-Pole Miniature Circuit Breaker C Curve 277V 15kAIC DIN Rail Mount

Save $80.86
SKU: FAZ-C20/1-SP-New
Condition: New
Price:
$41.95 $122.81
Stock:
2 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

FAZ-C20/1-SP - Eaton Moeller/ Eaton Feed-Thru 20 Amp 1 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
FAZ-C20/1-SP - Eaton Moeller/ Eaton Feed-Thru 20 Amp 1 Pole Circuit Breaker - Essential Electric Supply

Description

FAZ-C20/1-SP


FAZ-C20/1-SP is a single-pole Eaton miniature circuit breaker designed for reliable protection in industrial and control panel applications. This UL 1077 supplementary protector features a C curve trip characteristic, making it ideal for loads with medium inrush currents such as small transformers and pilot devices. It mounts easily on standard 35 mm DIN rail and offers robust protection for branch circuits. The Eaton FAZ-C20/1-SP provides thermal magnetic protection with a 20A current rating, 277VAC voltage rating, and a 15 kAIC interrupting capacity. It is certified to UL 1077, CSA C22.2 No.235, and IEC 60947-2 standards, ensuring compliance for a wide range of applications. The breaker features standard screw terminals and is suitable for use in control panels, machine tools, and industrial equipment.
  • Part Number: FAZ-C20/1-SP
  • Manufacturer: Eaton
  • Series: FAZ
  • Amperage Rating: 20A
  • Number of Poles: 1
  • Voltage Rating: 277VAC
  • Interrupt Rating: 15 kAIC
  • Mounting Type: DIN Rail (35 mm)
  • Protection Curve: C Curve (5-10x In)
  • Certifications: UL 1077, CSA C22.2 No.235, IEC 60947-2
  • Terminal Type: Standard Screw
  • Application: Supplementary Protection, Control Panels, Industrial Equipment
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: FAZ-C20/1-SP
  • Manufacturer : Eaton
  • Brand : Eaton
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : FAZ Series
  • Type : FAZ
  • Voltage : 480
  • Amperage : 20
  • Phase : 1
  • Poles : 1
  • AIC rating : 10kA@277V
  • Connection : Din Rail
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • MCM Size : Min. Wire Size 18 AWG Max. Wire Size 4 AWG
  • Protection : Thermal Magnetic

Product Data

  • UPC : 01508163764
  • GTIN : 04015081637645
  • Country of Origin : Romania
  • Dimensions : 0.69 in x 1 in x 3 in (Length/Depth x Height x Width)
  • Weight : 0.2
  • Standards : CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Certification : CSA C22.2 No. 235, IEC 60947-2, UL 1077
