FAZ-B20/2-NA - Eaton 20A 277/480VAC 2-Pole Thermal Magnetic Circuit Breaker DIN Rail Mount

FAZ-B20/2-NA

FAZ-B20/2-NA is a 2-pole thermal magnetic circuit breaker from Eaton designed for reliable branch circuit protection.

This Eaton FAZ series breaker features a 20 ampere rating, 277/480VAC voltage rating, and a 14kA interrupting capacity. It mounts on a 35mm DIN rail and includes long time and instantaneous trip functions for precise protection. UL, CSA, IEC, CCC, and VDE certifications ensure compliance with global safety standards. The breaker supports wire sizes from 18 to 4 AWG with line and load terminal connections.

• Brand: Eaton
• Series: FAZ
• Amperage: 20A
• Voltage Rating: 277/480VAC
• Number of Poles: 2
• Mounting Type: 35mm DIN Rail
• Interrupting Rating: 14kAIC
• Trip Unit: Thermal Magnetic with LI (Long Time and Instantaneous)
• Connection Type: Feed-Thru, Line and Load Terminals
• Wire Gauge: 18 to 4 AWG
• Certifications: UL, CSA, IEC, CCC, VDE
• RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B20/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 14kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 001508129655
• GTIN : 04015081296552
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL, CSA, IEC, CCC, VDE
• Wire Size : 18 to 4 AWG
