FAP36070TF - Square D 70 Amp 600 Volt 3 Pole Molded Case Circuit Breaker Thermal Magnetic I-Line

FAP36070TF

FAP36070TF is a 3 pole, 70 amp, 600 volt molded case circuit breaker from Square D featuring thermal magnetic trip technology and I-Line mounting.

This circuit breaker is designed for reliable protection of electrical circuits with a thermal magnetic trip unit and I-Line bolt-on mounting style. It supports a 70 amp line rated current and is suitable for use in 600 volt systems. The breaker has interrupt ratings of 25kA at 240VAC, 18kA at 480VAC, and 14kA at 600VAC, ensuring effective fault current interruption. This model is part of the Square D FAP series and provides robust circuit protection in commercial and industrial applications.

• Manufacturer: Square D
• Part Number: FAP36070TF
• Amperage: 70 Amp
• Voltage: 600 Volt
• Number of Poles: 3
• Mounting Type: I-Line Bolt-On
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Series/Frame: FAP

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAP36070TF
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAP Series
• Type : FAP
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785902000000
• GTIN : 00785901699408
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 5
