FAL36045 - Square D 45 Amp 600V 3 Pole FAL Series Molded Case Circuit Breaker, Thermal Magnetic, Feed-Thru, UL/CSA

FAL36045

FAL36045 is a Square D 3-pole molded case circuit breaker designed for reliable protection in commercial and industrial power distribution applications.

This thermal magnetic circuit breaker features a 45 Amp current rating, 600V voltage rating, and is part of the FAL series. It offers feed-thru connection with line and load side lug terminals, unit mounting, and includes both long-time and instantaneous trip functions. The FAL36045 is UL and CSA certified for safety and compliance.

Key Specifications
• Amperage: 45A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Unit
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC
• Series/Frame: FAL
• Trip Unit: Thermal Magnetic, LI (Long-Time and Instantaneous)
• Connection: Feed-Thru, Line and Load Side Lug Terminals
• Certifications: UL, CSA
• Dimensions: 6.4" H x 4.5" W x 4.13" D
• Wire Compatibility: AWG 14 to 1/0 copper, AWG 12 to 1/0 aluminum

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAL36045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAL Series
• Type : FAL
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901529750
• GTIN : 00785901529750
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 4.817
• Certification : UL, CSA
• Wire Size : AWG 14, AWG 1/0 copper)1, AWG 12, AWG 1/0 aluminium)1
