FAL341001380 - Square D 100A 480V 3 Pole Molded Case Circuit Breaker Feed-Thru 18kA Interrupt Rating

FAL341001380

This circuit breaker from the FAL Series features a 3-pole configuration, 100 amp frame and trip rating, and a 480V AC voltage rating. It includes a feed-thru design, 18kA interrupting capacity at 480V, and is equipped with a 120/240Vac shunt trip and 1A/1B auxiliary switch. The breaker has thermal magnetic trip units with long-time and instantaneous trip functions, line and load side lug terminals, and is UL and CSA certified for safety and reliability.

Key Specifications
• Amperage: 100A
• Voltage Rating: 480V AC
• Poles: 3
• Interrupting Capacity: 18kA @ 480V
• Series/Frame: FAL Series
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Mounting Type: Feed-Thru
• Auxiliary Switch: 1A/1B
• Shunt Trip: 120/240Vac
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Additional Information

complete with 120/240Vac shunt trip and 1A/1B aux switch




Specifications

• Part Number: FAL341001380
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAL Series
• Type : FAL
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 785901478499
• GTIN : 00785901103622
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 5
