Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
FAL34090
FAL34090 is a Square D 3 pole molded case circuit breaker rated for 90 amps and 480 volts with bolt-on mounting.
This circuit breaker features an adjustable thermal magnetic trip unit, F frame, and is designed for use at 480 VAC and 250 VDC. It has a 3 pole configuration and a bolt-on mounting type. The breaker is UL listed and CSA certified, with interrupt ratings of 18kA at 480 VAC and 10kA at 250 VDC, suitable for industrial and commercial applications.
- Amperage: 90 Amps
- Voltage: 480 VAC / 250 VDC
- Poles: 3
- Mounting Type: Bolt-On
- Frame Type: F Frame
- Trip Unit: Adjustable Thermal Magnetic
- Interrupt Rating: 18kA @ 480 VAC, 10kA @ 250 VDC
- Certifications: UL Listed, CSA Certified
- Series: FAL
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FAL34090
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAL Series
- Type : FAL
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 785901423423
- GTIN : 00785901423423
- Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
- Weight : 4.65
- Certification : UL, CSA
