Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
FAL22035
FAL22035 is a 2-pole molded case circuit breaker manufactured by Square D with a rated amperage of 35 amps and voltage rating of 240VAC. This thermal magnetic circuit breaker is designed for reliable overcurrent protection in commercial and industrial applications. The unit features unit mount configuration with lugs on both line and load sides for secure terminal connections. Key Specifications
- Amperage: 35 Amps
- Poles: 2
- Voltage: 240VAC
- Interrupt Rating: 10kA at 240VAC
- Type: Thermal Magnetic Molded Case
- Mounting: Unit Mount
- Line Side Termination: Lugs
- Load Side Termination: Lugs
- Magnetic Hold Current: 400A
Specifications
- Part Number: FAL22035
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAL Series
- Type : FAL
- Voltage : 240
- Amperage : 35
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 785901563709
- GTIN : 00785901563709
- Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
- Weight : 3.15
- Certification : UL LISTED-CSA
