Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
FAL12020
FAL12020 is a 1 pole molded case circuit breaker from Square D designed for reliable thermal magnetic protection in single-phase applications.
This FAL series breaker delivers consistent performance with long-time and instantaneous trip functions. The Feed-Thru connection type allows for flexible installation configurations in power distribution systems. Built to standard interrupting capacity ratings, the FAL12020 provides dependable overcurrent protection for residential and light commercial installations.
- Amperage: 20 Amps
- Poles: 1
- Voltage: 120VAC
- Series: FAL
- Frame Type: F Frame
- Connection: Feed-Thru
- Trip Functions: Long-Time and Instantaneous
- Interrupting Rating: 10kA at 120VAC, 10kA at 240VAC, 5kA at 48VDC
- Thermal Magnetic Protection
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FAL12020
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAL Series
- Type : FAL
- Voltage : 120
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 785901342465
- GTIN : 00785901342465
- Dimensions : 6.4 in (162.6 mm) x 1.5 in (38.1 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
- Weight : 1.906
- Certification : UL, CSA
- Wire Size : Standard
