FAF32045 - Square D 45 Amp 3 Pole 240V I-Line Molded Case Circuit Breaker Thermal Magnetic

FAF32045

FAF32045 is a Square D 3 Pole molded case circuit breaker with a 45 Amp rating and 240 Volt capacity designed for I-Line mounting.

This thermal magnetic circuit breaker features long time and instantaneous trip functions, providing reliable protection for electrical circuits. It supports 3-phase power with a 10kA interrupting rating at 240VAC and 5kA at 250VDC. The breaker uses a plug-in I-Line style connection and is UL and CSA certified, suitable for use with wire gauges from AWG 14 to AWG 1/0 in aluminum or copper. It is rated for operation at 40 degrees Celsius and complies with RoHS and HACR standards.

• Amperage: 45 Amp
• Voltage: 240VAC, 250VDC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupting Rating: 10kA at 240V
• Frame Type: FA
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Terminal Connection: Load Side Lug
• Wire Gauge Range: AWG 14 to AWG 1/0, Aluminum/Copper
• Certifications: UL, CSA
• Standards: RoHS, HACR
• Temperature Rating: 40 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: FAF32045
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAF Series
• Type : FAF
• Voltage : 240
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 4
