FA340201021 - Square D I-Line 480V 20A 3 Pole Molded Case Circuit Breaker

FA340201021

FA340201021 is a Square D I-Line style plug-in molded case circuit breaker rated for 480 volts, 20 amperes, and 3 poles with thermal magnetic trip protection. This circuit breaker is designed for use in Class 650/651 I-Line panelboards and switchboards, featuring a standard interrupting rating of 18kA at 480V and 25kA at 240V. The breaker includes 120Vac shunt trip capability and operates at 40 degrees Celsius ambient temperature.

• Part Number: FA340201021
• Manufacturer: Square D (Schneider Electric)
• Frame Type: FA
• Amperage: 20 Amps
• Voltage: 480V
• Poles: 3
• Mounting: I-Line plug-in
• Interrupt Rating: 18kA @ 480V, 25kA @ 240V
• Trip Unit: Thermal magnetic with shunt trip
• Phase Connection: ABC three-phase
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA340201021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901255123
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 9
• Certification : UL
