FA26100AC - Square D 100 Amp 600V 2 Pole Thermal Magnetic Circuit Breaker I-Line Mount

FA26100AC

FA26100AC is a Square D 2 Pole thermal magnetic molded case circuit breaker rated for 100 Amps and 600VAC with I-Line mounting.

This FA series circuit breaker features a 2-pole design with a 100 Amp line rated current and thermal magnetic trip unit technology. It supports voltages up to 600VAC and 250VDC, with interrupting ratings of 25kAIC at 240V, 18kAIC at 480V, and 14kAIC at 600V. The breaker mounts using the I-Line style plug-in connection and includes long-time and instantaneous trip functions. It is UL and CSA certified and designed for reliable protection in industrial and commercial electrical distribution systems.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 600 VAC, 250 VDC
• Number of Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupting Rating: 25kAIC @ 240V, 18kAIC @ 480V, 14kAIC @ 600V
• Frame Type: F Frame
• Trip Unit: Thermal Magnetic with Long-Time & Instantaneous
• Certifications: UL Listed, CSA Certified
• Phase: Single Phase
• Connection Type: I-Line Style Plug-In
• Temperature Rating: 40 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA26100AC
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 600
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901254089
• GTIN : 00785901254089
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
