FA24040BC - Square D 40 Amp 2 Pole 480V I-Line Plug-In Molded Case Circuit Breaker, 18kA Interrupt, Frame FA, Thermal Magnetic Trip, UL/CSA Certified

FA24040BC

FA24040BC is a Square D 40 Amp, 2 pole, 480V I-Line plug-in molded case circuit breaker designed for industrial power distribution applications.

This breaker features a thermal magnetic trip unit, 18kA interrupting rating at 480V, and is certified for use in UL and CSA listed panelboards and switchboards. It is part of the FA frame series and is rated for 240/480VAC at 50/60Hz, with a plug-on mounting style for easy installation in compatible I-Line equipment.

Key Specifications
• Part Number: FA24040BC
• Manufacturer: Square D
• Amperage: 40A
• Voltage: 480V AC (also rated 240V AC, 250V DC)
• Poles: 2
• Mounting Type: Plug-In (I-Line)
• Interrupt Rating: 18kA at 480V AC
• Series/Frame: FA
• Trip Unit: Thermal Magnetic
• Certifications: UL, CSA
• Terminal Wire Size: 14–1/0 AWG (copper), 12–1/0 AWG (aluminum)
• Application: Power distribution in panelboards and switchboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA24040BC
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 480
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901253532
• GTIN : 00785901253532
• Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
