Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
EQ8695
EQ8695 is a Siemens 200A, 2-pole, 120/240V AC main circuit breaker designed for single-phase load centers. This molded case circuit breaker features a 22kA interrupting rating and is UL listed for reliable electrical protection. Engineered for Siemens single-phase load centers, the EQ8695 offers bolt-on mounting for secure installation and supports wire sizes from #4 to 300 kcmil copper or aluminum. It is suitable for main breaker applications and can be ordered with a shunt trip option using the ST suffix.
- Part Number: EQ8695
- Manufacturer: Siemens
- Amperage: 200A
- Voltage: 120/240V AC
- Poles: 2
- Mounting Type: Bolt-on
- Interrupting Rating: 22kA
- Series/Frame: EQ
- Application: Main Breaker
- Wire Range: #4 – 300 kcmil Cu/Al
- Shunt Trip Option: Available (ST suffix)
- Certifications: UL Listed
Specifications
- Part Number: EQ8695
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : EQ Series
- Type : EQ
- Voltage : 240
- Amperage : 200
- Phase : 1
- Poles : 2
- AIC rating : 22kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783643387911
- GTIN : 00783643387911
- Country of Origin : Mexico
- Dimensions : 5.906 x 3.937 x 3.937 inch
- Weight : 1.411
