Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3080LBP10
EHD3080LBP10 is an Eaton Series C complete molded case circuit breaker designed for industrial and commercial electrical protection applications. This three-pole, 80 ampere circuit breaker features a fixed thermal and fixed magnetic trip mechanism for precise protection against overloads and short circuits. The F-frame design provides robust performance with a frequency rating of 50/60 Hz, making it suitable for various electrical systems requiring reliable fault current protection. Key Specifications
- Amperage Rating: 80 A
- Number of Poles: 3
- Circuit Breaker Type: EHD
- Frame Type: F-frame
- Series: C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 18 kAIC at 240 Vac; 14 kAIC at 480 Vac
- Frequency Rating: 50/60 Hz
- Mounting: Load side
- Certifications: UL Listed
- Dimensions: 4.13 in W x 6.0 in H x 3.38 in D
- Weight: 4.3 lb
Specifications
- Part Number: EHD3080LBP10
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 80
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
