Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3035LBP10
EHD3035LBP10 is a three-pole, 35A molded case circuit breaker from Eaton's Series C F-frame line, designed for reliable circuit protection in commercial and industrial applications. This Eaton Series C F-frame circuit breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overload and short-circuit protection. It is suitable for use in panelboards, switchboards, and motor control centers, supporting a wide range of industrial and commercial power distribution needs.
- Series: Series C
- Frame: F-frame
- Amperage Rating: 35 A
- Number of Poles: 3
- Voltage Rating: 600 Vac
- Interrupt Rating: 14 kAIC at 480 Vac
- Frequency: 50/60 Hz
- Mounting Type: Bolt-in
- Terminal Type: Multi-wire
- UL Listed: Yes
- Application: Commercial, Industrial
Specifications
- Part Number: EHD3035LBP10
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 35
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
