Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD2090LBP10
EHD2090LBP10 is a 90-ampere, two-pole, 480-volt molded case circuit breaker from Eaton's Series C family with an F-frame design and fixed thermal-magnetic trip unit. This complete breaker is rated for 14 kAIC at 480 Vac and 18 kAIC at 240 Vac, making it suitable for standard industrial and commercial power distribution applications. The breaker features line and load terminals, operates at 50/60 Hz, and is UL Listed for safety and performance.
- Amperage Rating: 90 A
- Number of Poles: Two-pole
- Voltage Rating: 480 Vac
- Interrupt Rating: 14 kAIC at 480 Vac, 18 kAIC at 240 Vac
- Series: Series C
- Frame Type: F-frame
- Trip Type: Fixed thermal, fixed magnetic (T186)
- Circuit Breaker Type: EHD Complete Breaker
- Frequency: 50/60 Hz
- Terminals: Line and load
- Certifications: UL Listed
- Warranty: One year from installation or eighteen months from shipment, whichever occurs first
Specifications
- Part Number: EHD2090LBP10
- Manufacturer : Eaton
- Brand : Culter Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 90
- Phase : 1
- Poles : 2
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 3
