EHD2070L - Cutler Hammer 70 Amp 480VAC 2 Pole Molded Case Circuit Breaker, Series C, F-Frame, Thermal Magnetic Trip, 14kAIC, Feed-Thru, UL Listed

EHD2070L

EHD2070L is a Cutler Hammer molded case circuit breaker designed for reliable protection in commercial and industrial applications.

This 2-pole, 70 amp breaker features a thermal magnetic trip unit, feed-thru connection, and is rated for 480VAC with an interrupting capacity of 14kAIC. It is part of the Series C, F-Frame family and is UL listed for safety and compliance.

Key Specifications
• Part Number: EHD2070L
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 70A
• Voltage: 480VAC (also rated 277VAC/125VDC/250VDC per variant)
• Poles: 2
• Mounting Type: Molded case, feed-thru
• Interrupt Rating: 14kAIC at 480VAC, 18kAIC at 240VAC
• Series/Frame: Series C, F-Frame
• Trip Unit: Thermal magnetic, LI (Long-Time and Instantaneous)
• Certifications: UL listed
• Connection: Line and load side lug terminals
• Temperature Rating: 40°C
• Dimensions: 6" H x 2.75" W x 3.38" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2070L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679850916
• GTIN : 00786679850916
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
