EHD2070 - Cutler Hammer 70A 480V 2-Pole F-Frame Molded Case Circuit Breaker

EHD2070

EHD2070 is a Cutler Hammer 2-pole molded case circuit breaker rated for 70 amps and 480 volts AC. It features thermal magnetic trip units for reliable circuit protection.

This Eaton Series C EHD breaker has an F-frame design with a bolt-on mounting type. It provides an interrupt rating of 18 kA at 240 VAC and 14 kA at 480 VAC, suitable for single-phase applications. The breaker includes line and load side lug terminals and is UL listed for safety compliance.

Key Specifications
• Amperage: 70 Amps
• Voltage Rating: 480 VAC / 250 VDC
• Poles: 2
• Frame Type: F-Frame
• Mounting Type: Bolt-On
• Interrupt Rating: 18 kA at 240 VAC, 14 kA at 480 VAC
• Trip Unit: Thermal Magnetic (non-interchangeable)
• Phase: Single-phase
• Connection: Feed-thru terminals
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2070
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317495
• GTIN : 00786679317495
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
