EHD2035L - Cutler Hammer 35A 480V 2 Pole Molded Case Circuit Breaker Type EHD 14kAIC

EHD2035L

EHD2035L is a Cutler Hammer Type EHD molded case circuit breaker rated for 35 amps and 480 volts with 2 poles and a 14kA interrupt rating.This circuit breaker is part of the Eaton Series C family featuring a fixed thermal and fixed magnetic trip unit. It supports panel mounting and is designed for 50/60 Hz frequency operation. The breaker has a maximum interrupt rating of 14kA at 480 VAC and 18kA at 240 VAC. It is UL 489 certified and weighs approximately 3 lbs.

• Amperage: 35A
• Voltage Rating: 480 VAC max
• Number of Poles: 2
• Interrupt Rating: 14kA at 480 VAC, 18kA at 240 VAC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Panel mount
• Series/Frame: Eaton Series C, Type EHD
• Frequency: 50/60 Hz
• UL Certification: UL 489
• Weight: 3 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2035L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 35
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679850879
• GTIN : 00786679850879
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
