EHD2030L - Cutler Hammer 30 Amp 480 Volt 2 Pole Molded Case Circuit Breaker F Frame

EHD2030L

EHD2030L is a Cutler Hammer 2 pole molded case circuit breaker rated for 30 amps and 480 volts, designed for reliable circuit protection.This Eaton Series C F-frame breaker features thermal magnetic trip units with a 14 kA interrupt rating at 480 VAC and 18 kA at 240 VAC. It supports line and load side connections and operates at 50/60 Hz frequency. The breaker is UL listed, ensuring compliance with safety standards.

• Amperage: 30 Amps
• Voltage: 480 VAC
• Poles: 2
• Frame: F Frame (Series C)
• Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Molded Case
• Frequency Rating: 50/60 Hz
• Terminals: Line and Load
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2030L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679411360
• GTIN : 00786679411360
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
