Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD2015VSH09
EHD2015VSH09 is an Eaton Series C molded case circuit breaker designed for reliable power distribution and protection in industrial and commercial applications. This F-frame, two-pole breaker delivers fixed thermal and magnetic trip protection with a 15-ampere rating and operates at 50/60 Hz frequency. The breaker features stainless steel load-side terminals and is rated for 14 kAIC at 480 Vac and 18 kAIC at 240 Vac, providing robust interrupt capacity for demanding electrical systems. Built to UL 489 standards, this complete molded case circuit breaker combines durability with precise overcurrent protection.
- Amperage Rating: 15 A
- Poles: 2-Pole
- Series: Series C
- Frame Type: F-Frame
- Trip Type: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 14 kAIC at 480 Vac, 18 kAIC at 240 Vac
- Frequency: 50/60 Hz
- Terminal Material: Stainless Steel
- Terminals: Load Side
- Certifications: UL 489
- Height: 6 inches
- Weight: 3 pounds
Specifications
- Part Number: EHD2015VSH09
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
Product Data
- UPC : 786679040928
- GTIN : 00786679000000
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL 489
