EHD2010 - Westinghouse 2-Pole 10A 480V Molded Case Circuit Breaker, EHD Series, Thermal Magnetic Trip, Bolt-On Mount, UL Listed

EHD2010

EHD2010 is a Westinghouse molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This 2-pole breaker features a 10A current rating, 480V voltage rating, and a thermal magnetic trip unit for dependable overload and short-circuit protection. It is part of the EHD series and is suitable for panelboard, switchboard, motor control center, and busway installations. The breaker offers a bolt-on mounting type for secure electrical connections and is certified for safety and performance.

Key Specifications
• Part Number: EHD2010
• Manufacturer: Westinghouse
• Amperage: 10A
• Voltage: 480V
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 18 kAIC at 240V, 14 kAIC at 480V
• Series/Frame: EHD
• Trip Unit: Fixed thermal, fixed magnetic
• Connection: Load side
• Frequency: 50/60 Hz
• Certifications: UL Listed
• Dimensions: 2.75 in W x 3.38 in D x 6 in H
• Weight: 2.8 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2010
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 10
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317402
• GTIN : 00786679317402
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 2.8
• Certification : UL Listed
