EHB3100VL - Eaton 100A 480V 3 Pole Molded Case Circuit Breaker Series C F-Frame Bolt-In

Name: EHB3100VL - Eaton 100A 480V 3 Pole Molded Case Circuit Breaker Series C F-Frame Bolt-In
Brand: Cutler Hammer
SKU: EHB3100VL-ReCert
Price: 322.75 USD
Availability: InStock

SKU: EHB3100VL-ReCert

Condition: Re-Certified

Variant

Price:

$322.75

Stock:

Low inventory, please call for stock check
This ships in 1-2 business days

Quantity:

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Enter your ZIP code:

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Manufacturer:Eaton
Sub-Category:Molded Case

EHB3100VL Westinghouse Molded Case Circuit Breaker AB DE-ION 100A 480V - Essential Electric Supply

Roll over image to zoom in Click on image to zoom Images are for reference only

EHB3100VL

EHB3100VL is a three-pole molded case circuit breaker from Eaton's Series C line, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 100A current rating and is rated for up to 480V AC, making it suitable for a wide range of applications requiring robust circuit protection. The EHB3100VL is a bolt-in mounting type, ensuring secure installation and easy replacement in compatible panels. It utilizes a fixed thermal and fixed magnetic trip unit for dependable overload and short-circuit protection. The breaker is UL Listed and built to meet rigorous safety and performance standards. Eaton's Series C molded case circuit breakers are known for their durability and compatibility with a variety of electrical systems. The EHB3100VL is constructed with an F-frame and is designed for use in panelboards, switchboards, and motor control centers. Its robust interrupt rating ensures reliable operation under fault conditions, and its bolt-in mounting simplifies installation and maintenance.

Part Number: EHB3100VL
Manufacturer: Eaton
Amperage Rating: 100A
Maximum Voltage: 480V AC
Number of Poles: Three Pole
Mounting Type: Bolt-In
Interrupt Rating: 14 kAIC at 480V AC
Series: Series C
Frame: F-Frame
Frame Type: Complete Breaker
Terminal Type: Load Side
Frequency Rating: 50/60 Hz
Warranty: 1 year from installation or 18 months from shipment
Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

Part Number: EHB3100VL
Manufacturer : Eaton
Category : Circuit Breaker
Item Subcategory : Molded Case
Family : AB DE-ION
Type : EHB
Voltage : 480
Amperage : 100
Phase : 3
Poles : 3
AIC rating : 14kA@480V
Connection : Bolt-On
Functions : LI - Long-Time and Instantaneous
Protection : Thermal Magnetic

Product Data

Weight : 11

Accesories

Part	Manufacture	Sub Category
373D958G05	Eaton	Parts And Accessories

Related Products

Part	Manufacture	Voltage	Amperage	Phase	AIC	Connection	Poles	Functions
ehb3100lk	Westinghouse	480V	100	3	14kA@480V	Feed-Thru	3	NA - No Overcurrent Protection
ehb3100l	Westinghouse	480V	100	3	14kA@480V	Feed-Thru	3	LI - Long-Time and Instantaneous
ehb3100sl	Westinghouse	480V	100	3	14kA@480V	Feed-Thru	3	LI - Long-Time and Instantaneous
ehb3100vl	Cutler Hammer	480V	100	3	14kA@480V	Bolt-On	3	LI - Long-Time and Instantaneous
ehb3100n	Westinghouse	480V	100	3	14kA@480V	Bolt-On	3	NA - No Overcurrent Protection
