Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
EHB2100L
EHB2100L is a Westinghouse 2 pole, 100 amp, 480 volt thermal magnetic molded case circuit breaker designed for reliable industrial electrical protection.This circuit breaker features a bolt-on mounting type and is part of the EHB frame series. It provides a 14kA interrupt rating at 480 volts AC and includes long time and instantaneous trip functions with thermal magnetic trip units. The breaker supports load side lug terminals and is suitable for single-phase applications.
- Key Specifications
- Amperage: 100A
- Voltage: 480V AC
- Poles: 2
- Frame Type: EHB
- Mounting Type: Bolt-On
- Interrupt Rating: 14kA at 480V
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous Functions
- Terminals: Load Side Lug
- Phase: Single Phase
- Part Number: EHB2100L
- Manufacturer : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : AB DE-ION
- Type : EHB
- Voltage : 480
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- Weight : 6
