EGS3060FFG Eaton Series G EG-Frame Molded Case Circuit Breaker, 60 A, 3-Pole

EGS3060FFG

EGS3060FFG Eaton Series G EG-Frame Molded Case Circuit Breaker, 60 A, 3-Pole

EGS3060FFG is an Eaton Series G complete molded case circuit breaker with an EG frame, three poles, and a 60 A rating. It uses a fixed thermal and fixed magnetic trip and carries a 600Y/347 Vac voltage rating.

Eaton specifies interrupt ratings of 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 22 kAIC at 600Y/347 Vac. The exact configuration includes line and load terminals and operates at 50/60 Hz.

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Common Applications

• Branch-circuit overcurrent protection in industrial control panels
• Disconnecting means where the verified ratings meet the system design
• Global equipment designs requiring documented UL, CSA, IEC, and CE acceptance

Key Features

• Complete breaker: EG frame, trip unit, line and load terminals, and mounting hardware configuration
• Trip design: Fixed thermal and fixed magnetic operation
• Performance class: 35 kAIC interrupt rating at 480 Vac
• Global platform: UL Listed, CSA Certified, IEC Rated, and CE Marked

Specifications

• Amperage rating: 60 A
• Voltage rating: 600Y/347 Vac
• Number of poles: Three-pole
• Trip configuration: Fixed thermal, fixed magnetic
• Trip type: T186
• Frequency rating: 50/60 Hz
• Interrupt rating at 240 Vac: 85 kAIC
• Interrupt rating at 480 Vac: 35 kAIC
• Interrupt rating at 600Y/347 Vac: 22 kAIC
• Terminals: Line and load

Product Identification

• Catalog number: EGS3060FFG
• Manufacturer: Eaton
• Series: Series G
• Frame: EG
• Product dimensions: 2.99 in depth x 3 in width x 5.5 in height
• Product weight: 3 lb
• UPC: 782114877173

FAQ

What is EGS3060FFG?

It is an Eaton Series G complete EG-frame molded case circuit breaker rated 60 A with three poles.

What trip mechanism does this breaker use?

The unit has fixed thermal and fixed magnetic trip operation, identified by Eaton as trip type T186.

What is its interrupt rating at 480 Vac?

Eaton publishes a 35 kAIC interrupt rating at 480 Vac for this catalog number.

Are terminals included in the configuration?

Yes. The exact specification identifies line and load terminals.

Is EGS3060FFG listed and certified?

Eaton lists it as UL Listed, CSA Certified, IEC Rated, and CE Marked.

Specifications

• Part Number: EGS3060FFG
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGS
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782114877173
• GTIN : 00782114877173
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 3 lb
• Certification : IEC Rated,CSA Certified,UL Listed,CE Marked
