EGS2050FFB - Cutler Hammer 50A 600V 2-Pole Molded Case Circuit Breaker EG Frame Bolt-On

EGS2050FFB

EGS2050FFB is a Cutler Hammer 2-pole molded case circuit breaker rated for 50 amps and 600 volts with a bolt-on mounting type.

This circuit breaker features a fixed thermal and fixed magnetic trip unit, EG frame, and an interrupt rating of 35kA at 480V AC. It is designed for use in industrial and commercial power distribution applications, providing reliable overcurrent protection. The breaker meets UL 489 standards and carries CE, CSA, and IEC certifications. It is suitable for 600Y/347 VAC systems and mounts via bolt-on terminals for secure installation.

• Amperage: 50 A
• Voltage: 600Y/347 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 35kA at 480V AC, 22kA at 600Y/347V AC, 85kA at 240V AC
• Frame: EG
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Certifications: UL 489, CE, CSA, IEC
• Series: G Series
• Terminal Type: Bolt-On
• Country of Origin: US

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGS2050FFB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGS
• Voltage : 600
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685232669
• GTIN : 00786685232669
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : IEC Rated,UL Listed,CSA Certified,CE Marked
