Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGS1020FFB
EGS1020FFB is a 20 Amp, 1 Pole, 240 Volt bolt-on molded case circuit breaker from Cutler Hammer's Series G line.This circuit breaker features a fixed thermal magnetic trip unit with interrupt ratings of 85kA at 240VAC, 35kA at 480VAC, and 22kA at 600Y/347VAC. It is designed for use in 50/60 Hz systems and mounts via bolt-on configuration. The breaker meets industry certifications and is suitable for reliable circuit protection in commercial and industrial applications.
- Amperage: 20 Amps
- Voltage: 240 VAC (also rated 600Y/347 VAC)
- Poles: 1 Pole
- Mounting Type: Bolt-On
- Interrupt Rating: 85kA @ 240 VAC, 35kA @ 480 VAC, 22kA @ 600Y/347 VAC
- Series/Frame: Series G
- Trip Unit: Fixed Thermal Magnetic
- Frequency: 50/60 Hz
- Certifications: Industry standard certifications (UL listed, etc.)
Specifications
- Part Number: EGS1020FFB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGS
- Voltage : 240
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 85kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786685381978
- GTIN : 00786685381978
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 1 in (Length/Depth x Height x Width)
- Weight : 1
- Certification : CSA Certified,IEC Rated,UL Listed,CE Marked
