Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGH3040FFB
EGH3040FFB is a Cutler Hammer Series G EG-frame molded case circuit breaker designed for reliable circuit protection.This 3-pole breaker features a fixed thermal and fixed magnetic trip unit, rated for 40 amps and 600Y/347 volts AC. It offers a high interrupting capacity of up to 65kA at 480V, suitable for demanding industrial and commercial applications. The bolt-on mounting type ensures secure installation in panelboards.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 40A
- Voltage: 600Y/347 VAC
- Poles: 3
- Frame Type: EG (Series G)
- Interrupt Rating: 65kA @ 480V
- Trip Unit: Fixed thermal, fixed magnetic
- Mounting Type: Bolt-On
- Phase: 3
- Certifications: UL Listed
- Part Number: EGH3040FFB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGH
- Voltage : 600
- Amperage : 40
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
- UPC : 786685381879
- GTIN : 00786685381879
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : CSA Certified,IEC Rated,UL Listed,CE Marked
