Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGH3015FFB
EGH3015FFB is a Cutler Hammer 3-pole molded case circuit breaker rated for 15 amps and 600 volts. It features a thermal magnetic trip unit for reliable protection.
This EG-frame Series G breaker provides fixed thermal and magnetic trip functions with a high interrupting capacity suitable for residential, commercial, and industrial applications. It supports bolt-on mounting and line and load side lug terminals. The breaker is rated for 100 kA interrupting capacity at 240 VAC and 65 kA at 480 VAC, ensuring robust fault current protection.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 15 Amps
- Voltage Rating: 600Y/347 VAC
- Poles: 3
- Frame Type: EG (Series G)
- Trip Unit: Fixed Thermal Magnetic
- Interrupting Rating: 100 kA at 240 VAC, 65 kA at 480 VAC
- Mounting Type: Bolt-On
- Terminal Type: Line and Load Side Lug Terminals
- Certifications: UL Listed
- Part Number: EGH3015FFB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGH
- Voltage : 600
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 786685381824
- GTIN : 00786685381824
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 2.91
- Certification : UL Listed,IEC Rated,CSA Certified,CE Marked
