EGE3110FFG - Cutler Hammer 110A 600V 3 Pole Molded Case Circuit Breaker EG Frame

EGE3110FFG

EGE3110FFG is a Cutler Hammer molded case circuit breaker designed for 110 ampere current rating and 600 volts AC operation with 3 poles and EG frame type.

This circuit breaker features a fixed thermal and fixed magnetic trip unit, providing reliable long-time and instantaneous trip protection. It supports a voltage rating of 600Y/347 VAC and an interrupt rating up to 35 kAIC at 240 VAC. The breaker includes line and load side lug terminals and is suitable for feed-thru applications in three-phase systems.

• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 110 A
• Voltage Rating: 600Y/347 VAC
• Poles: 3
• Frame Type: EG
• Trip Unit: Fixed thermal, fixed magnetic
• Interrupt Rating: Up to 35 kAIC at 240 VAC
• Mounting Type: Molded case
• Line & Load Side Lug Terminals
• Feed-Thru capable
• Series: Series G
• Certifications: UL Listed (implied by manufacturer standards)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGE3110FFG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGE
• Voltage : 600
• Amperage : 110
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782114876831
• GTIN : 00782114876831
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 2.72
• Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
