EGE3090FFG - Cutler Hammer 90A 600Y/347VAC 3-Pole Molded Case Circuit Breaker Fixed Thermal/Magnetic Trip

EGE3090FFG

EGE3090FFG is a Cutler Hammer molded case circuit breaker designed for reliable protection in electrical distribution systems.This 3-pole circuit breaker features a 90 ampere rating and is rated for 600Y/347 VAC operation. It includes a fixed thermal and fixed magnetic trip unit for consistent performance. The breaker belongs to Eaton's Series G (EG-frame) and offers interrupt ratings of 35 kA at 240 VAC, 25 kA at 480 VAC, and 18 kA at 600Y/347 VAC. It is UL listed, CSA certified, IEC rated, and CE marked, ensuring compliance with major safety standards. The breaker supports line and load connections and is suitable for DIN rail mounting.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: EGE3090FFG
• Current Rating: 90 Amps
• Voltage Rating: 600Y/347 VAC
• Poles: 3
• Interrupt Rating: 35 kA @ 240 VAC, 25 kA @ 480 VAC, 18 kA @ 600Y/347 VAC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Series/Frame: Series G (EG-frame)
• Mounting Type: DIN Rail
• Certifications: UL Listed, CSA Certified, IEC Rated, CE Marked
• Terminal Type: Box Terminal
• Weight: Approximately 3 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGE3090FFG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGE
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782114876817
• GTIN : 00782114876817
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
